Professional Injection Molding Chiller Supplier in China
YuShine offers an injection molding chiller that can provide stable pressure.It also helps in increasing the injection molded product’s quality.We can manufacture based on your specifications.
• Precision temperature control
•Convenient to use and low maintenance
•Energy effect and cost-saving
• Customizable based on your requirements
YuShine Injection Molding Chillers
YuShine is an injection molding chiller manufacturer for over 10 years. We provide different types of chillers for plastic process, injection molding process, die cooling, and more applications that require a cooling system. We have different types of injection molding chillers such as screw chillers, scroll chillers, centrifugal chillers, rotary chillers, and so on. Our chillers offer accurate cooling temperature, microcomputer control, high cooling capacity, and high performance. YuShine can also provide you with customized injection molding chiller types to suit your requirements.
Send us your inquiries today!
Our Wide Range of Injection Molding Chiller
Our small water chiller has a 5kw capacity. It features a digital temperature control display, water tank inlet, condenser coils, pressure controller, aluminum condenser, and compressor.
The refrigerating machine offers a cooling process for plastic injection molding. It helps in enhancing the final product’s quality while minimizing the injection cycle.
YuShine manufactures plastic injection molding chillers that is widely used for 3D printing. It is integrated with precise temperature control and low noise operation.
Yushine’s injection molding chiller can help optimize the temperature of your process equipment such as plastic injection, blowing, and thermoforming vacuuming.
YuShine offers fully automated industrial mini water chillers that feature precise temperature control. It is integrated with high/low-pressure protection and high cooling capacity.
Our injection blow molding cooling system is available in water or air cooling type. It also features PLC, pressure vessels, high-quality pumps, and accurate temperature control.
Injection Molding Chillers by Features (4)
Our precision chillers for injection molding is controlled by a microcomputer. It offers accurate temperature control with user-friendly and easy to use design.
YuShine offers air-cooled chiller that features buffer tank. It has up to 30HP cooling capacity. These chillers feature compact design, safety protection, stainless steel water tank, and simple operation.
The air-cooled industrial injection molding chiller has a superior compressor to ensure low noise and high performance. It has a stainless steel temperature box for easy cleaning.
Our low-noise air-cooled chiller offers high efficiency, easy operation, and long service life. It is widely used for plastic injection cooling, mold cooling, die cooling, and more cooling purpose.
Injection Molding Chiller by Capacity (4)
Our 5HP air chiller machines are widely used for ultrasonic cooling, injection molding cooling, medical chemistry, and more. It features reasonable design, simple operation, and excellent quality.
We offer an injection molding chiller with a 15HP cooling capacity. These chillers offer high reliability, high efficiency, high-quality compressor, and high-performance condenser and evaporator.
Our 3Tones industrial water chiller is made manufactured with a superior quality compressor. Thus, it is an economical, low noise, and durable chiller for injection molding.
YuShine offers a 10Ton water chiller that features easy to clean, microcomputer controller, simple operation, low noise, and unit safety protection.
Premier Injection Molding Chiller Solution
The cooling process in injection molding takes up 80% of the time of the whole process. Therefore, we offer an injection molding chiller that can greatly minimize the cooling time.
YuShine manufactures fully automated injection molding chillers that are microcomputer controlled. It doesn’t need any cooling tower. Therefore, our chillers are convenient to use.
Our injection molding chillers have an excellent physical feature that helps in increasing heat dissipation area. It also provides an enhanced heat dissipation effect for efficient cooling.
Our injection molding chillers are made with stainless steel water tanks. It is also available in the powder-coated frame, high-quality evaporator, and condenser for efficient cooling and heat transfer.
Custom Injection Molding Chiller Solution
The cooling process in every injection molding industry depends on the plastic thickness, size, and type. That is why YuShine offers a custom injection molding chiller to meet your specific requirements.
We can produce these chillers based on your specific drawing, cooling capacity, applications, sizes, designs, and materials. YuShine can also customize different chillers according to your pump info and installation needs.
Contact us for your custom injection molding chiller needs!
Extensive Injection Molding Chiller Options
YuShine manufactures a wide range of injection molding chillers based on its functions and compressor. Below are some of our chiller options:
- Injection Molding Air Cooled Chiller. These chillers feature fans that force the air to remove heat. It is an ideal solution for stationary cooling because of its easy-to-install properties.
- Injection Molding Water Cooled Chiller. Water chillers function by pumping water to remove heat. Our water chillers are long-lasting and have a high performance.
Aside from that, we also supply other types of injection molding chillers based on compressor type such as screw-driven chillers, reciprocating chillers, scroll compression chillers, centrifugal chillers, and more.
We can customize injection molding chillers based on your specifications. Send us your inquiries today!
Why Choose YuShine Injection Molding Chillers
Our injection molding chillers can provide accurate temperature control. Therefore, reducing scrap count while allowing you to save cost. These chillers can also reduce production time while providing maximum and consistent plastic part quality.
Aside from that, YuShine offers injection molding chillers that feature less downtime, low maintenance, and excellent heat transfer. We are equipped with an advanced automated production line with a rich-experienced R&D team. Rest assured that YuShine has full capabilities in providing you with custom injection molding chillers!
Send us your inquiries today!
Why Yushine Chillers For Plastic Injection Molding
Energy savings of up to 50% and improved temperature control
Includes tiny portable chillers ranging from 1 to 15 tons, followed by bigger portable and central types. These machines are jam-packed with features that are either “firsts” in the field of process chilling, or are still extremely uncommon for smaller chillers, or basic capabilities that are often pricey extras. The most notable of them is variable-speed compressor technology, which has been utilized in the HVAC business for 20 years but supposedly never before in process cooling. The system monitors the process temperature and sends signals to the drive to accelerate or decelerate the compressor.
The new technology uses 30% to 50% less energy than conventional fixed-speed compressors. Other special features include variable-speed condenser fans with permanent-magnet motors, oversized evaporators, electronic expansion valve, compressor soft start, controls with extensive data collection, and remote-communication option for Industry 4.0. These characteristics are believed to work together to achieve extraordinarily tight temperature control of 0.5° F.
- Energy efficient
- Ozone friendly
- Microprocessor-based controller
- Excellent lubrication
- High-quality body materials
- Long-lasting equipment
- Powder-coated
- Clean energy
- Easy interface
- 100% quality and function tested
- Plastic injection molding
- Injection molding machines
- Factory furnaces
- Anodizing plants
- Medical process
- Laser technology
- Blow mold machines
- Laboratory equipment
- Food process industry
- Welding engineering
Custom Injection Molding Chillers to Skyrocket Your Business
- Highly efficient heat transfer and heat exchanger
- Microcomputer temperature controller
- Security and safety protection
- Stainless steel open tank
- Safe operation and low-noise
- Aluminum plate heat exchanger
- Accurate temperature control
- Available in water and air cooling type
- Low power consumption
- Low noise and large air volume
- Excellent cooling effect
- Microprocessor control and easy to operate
More About YuShine Injection Molding Chiller
- Gallery
- Data Sheet
- Details
Data Sheet
| Model Parameters | YB-01AF | YB-02AF | YB-03AF | YB-04AF | YB-05AF | YB-06AF | YB-08AF | YB-10AF | ||
| Cooling capacity | KW/hr | 50HZ | 2.94 | 5.67 | 8.39 | 10.90 | 13.95 | 16.90 | 21.80 | 28.01 |
| 60HZ | 3.44 | 6.63 | 9.82 | 12.75 | 16.32 | 19.77 | 25.50 | 32.78 | ||
| Kcal | 50HZ | 2528 | 4872 | 7216 | 9347 | 11990 | 14560 | 18748 | 24089 | |
| 60HZ | 2958 | 5701 | 8442 | 10698 | 14028 | 17000 | 21935 | 28184 | ||
| Temperature range | 3 °C – Room temperature (Below 0 °C can be customized) | |||||||||
| Power supply | 1N-22CV 50HZ / 60HZ | 3N-380V/415V 50HZ/60HZ | ||||||||
| Total power | KW | 1.27 | 2.02 | 2.85 | 3.65 | 4.86 | 5.61 | 7.65 | 9.9 | |
| Compressor Output | Type | Hermetic scroll type or piston | ||||||||
| KW | 0.75 | 1.50 | 2.20 | 3.00 | 3.75 | 4.50 | 6.00 | 7.5 | ||
| Blower | Air Flow M3/h | 1000 | 2000 | 3000 | 4000 | 5000 | 6000 | 8000 | 10000 | |
| Power KW | 0.14 | 0.14 | 0.28 | 0.28 | 0.36 | 0.36 | 0.9 | 0.9 | ||
| condensator | Form | Efficient brass sets corrugated aluminum fin | ||||||||
| Evaporator | Water Flow M3/h | 0.51 0.59 | 0.97 1.14 | 1.44 1.68 | 1.87 2.19 | 2.40 2.81 | 2.91 3.41 | 3.75 4.39 | 4.82 5.64 | |
| 0.59 | 1.14 | 1.68 | 2.19 | 2.81 | 3.41 | 4.39 | 5.64 | |||
| Water soluble content M3 | 0.028 | 0.040 | 0.050 | 0.050 | 0.065 | 0.065 | 0.16 | 0.16 | ||
| Inlet&outlet tube | G1/2″ | G1 | G1 | G1 | G1″ | G1″ | G1-1/2″ | G1-1/2″ | ||
| Circulating pump | Power KW | 0.37 | 0.37 | 0.37 | 0.37 | 0.75 | 0.75 | 0.75 | 1.5 | |
| Lift m | 22 | 22 | 22 | 22 | 23 | 23 | 23 | 21.5 | ||
| Machine size | L/mm | 680 | 800 | 1040 | 1140 | 1140 | 1200 | 1400 | 1400 | |
| W/mm | 420 | 480 | 555 | 620 | 620 | 650 | 725 | 725 | ||
| H/mm | 720 | 850 | 1060 | 1200 | 1200 | 1160 | 1450 | 1450 | ||
| Unit weight | KG | 60 | 90 | 130 | 140 | 170 | 210 | 270 | 350 | |
